Number of Columns 80 mm Paper:

• Font A - 42 columns
• Font B - 56 columns
• Font C - 56 columns
• Korean: 21 columns
• Chinese: 21 columns

Character Size:

• Font A: 1.50 ×3.00 mm (12 x 24 Dots)
• Font B: 1.13 ×3.00 mm (9 x 17 Dots)
• Font C: 1.00 x 2.0 mm (9 x 24 Dots)
• Korean: 24 x 24
• Chinese: 24 x 24
• Character Table/Code Alphanumeric: 95
• Pages: Expanded Graphics 128x37 page, International Character: 32

Bar-code Type:

• UPC-A/E, EAN-13/8, ITF, Code 39, Code 128, CODABAR, Code 93, PDF417, QR Code

Line Spacing:

• Paper feed method: Friction
• Paper Type: Thermal Paper Roll
• Paper Width: 80 ± 0.5mm or 58 ± 0.5mm
• Paper Roll Diameter Max: Ø 83.0mm

Paper Thickness:

• Paper Supply Method: Easy Paper Loading, Drop in and Print
• Auto Cutter
• Indicators/Controls: Power Light, Error Light, Paper Out Light
• Buzzer
• Emulation: ESC/POS
• Print Buffer: 4 KBytes
• NV Memory: 256 KBytes
• Sensors: Paper End Sensor , Paper near end sensor, Rear Cover Open Sensor
• Drawer Port: 1 port (opens 2 drawers, special cable is needed to open 2 drawers)
• External Device Port: N/A

Drivers Available:

• Smart Windows Driver, OPOS Driver, JPOS Driver, Linux CUPS Driver, Mac Driver

Software Utilities:

• Firmware/NV Image download
• Utility Software Package

Other:

• Power Supply Input: AC100 ~240V DC 24V, 2.5A
• Power Consumption Max: 60W
• External Dimensions (WxDxH)145 x 203 x 146 mm
• Weight Approx: 1.67 Kg
• Operating Environment: 0-45°C, 10-80% RH None condensing
• Storage Environment: -10-55°C, 10-80% RH None condensing
• Reliability Printer: 70 million Lines
• Head: 150 Km
• Auto Cutter: 1.8 Million cuts
• EMC/Safety Standards: UL, C-UL, FCC Class A, TUV-GS, CE, C-Tick
• Warranty: Limited 2 Year Back to Base warranty
